Máy nén khí Piston có dầu BEBICON











Máy nén khí Piston có dầu BEBICON

Lubricated BEBICON - Máy nén khí Piston có dầu BEBICON

Nội dung chi tiết:

Lubricated BEBICON - Máy nén khí Piston có dầu BEBICON

Lubricated BEBICON : Specifications

Automatic unloader type

Motor
Out-Put
(kW)

Item


Models

Compressor

Air tank

Motor

Standard accessories

Dimensions

Weight
Kg

(1)
Noise
level
dB[A]

Maximum
Pressure
(MPa)

Cylinder diameter(mm)
x stroke(mm)
x Quantity

Rotating
speed
min-1

Capacity
L/min

Capacity
L

W × D × H
mm

0.75

0.75U-9.5VS5A

0.93

50×65×1

990

80

62

Single phase

Pressure gauge,
Safety valve,
Hose joint,
V-belt,
Belt cover,
Silencer,
Stop value
0.75-1.5kW
1/4Bx1
2.2kW
1/4Bx2
3.7, 5.5kW
1/4Bx1
3/8Bx1
7.5, 11kW
1/4Bx1
3/4Bx1
15kW
1Bx1

931×376×816

71

70

0.75U-9.5V5A

Three phase

64

1.5

1.5U-9.5VS5A

72×65×1

970

165

80

Single phase

1,173×418×867

92

72

1.5U-9.5V5A

Three phase

80

2.2

2.2U-9.5VS5A

72×65×2

730

265

90

Single phase

1,283×434×894

114

72

2.2U-9.5V5A

Three phase

97

3.7

3.7U-9.5V5A

L)90×85×1
H)50×85×1

1,000

440

125

Three phase

1,345×428×948

125

74

5.5

5.5U-9.5V5A

L)105×85×1
H)60×85×1

1,080

630

150

1,470×482×979

186

76

7.5

7.5U-9.5V5A

L)90×85×2
H)72×85×1

950

840

230

1,643×547×1,103

242

79

11

11U-9.5V5A

L)105×85×2
H)82×85×1

1,050

1,200

250

1,793×611×1,103

308

83

15

15U-9.5VA5

L)110×110×2
H)82×110×1

1,000

1,650

280

1,983×734×1,221

462

84



Pressure-switch type

Motor
Out-Put
(kW)

Item


Models

Compressor

Air tank

Motor

Standard accessories

Dimensions

Weight
Kg

(1)
Noise
level
dB[A]

Maximum
Pressure
(MPa)

Cylinder diameter(mm)
x stroke(mm)
x Quantity

Rotating
speed
min-1

Capacity
L/min

Capacity
L

W × D × H
mm

0.75

0.75P-9.5VS5A

0.93

50×65×1

990

80

62

Single phase

Pressure gauge,
Safety valve,
Hose joint,
V-belt,
Belt cover,
Silencer,
Stop value
0.75-1.5kW
1/4Bx1
2.2kW
1/4Bx2
3.7, 5.5kW
1/4Bx1
3/8Bx1
7.5, 11kW
1/4Bx1
3/4Bx1

931×376×804

71

70

0.75P-9.5V5A

Three phase

64

1.5

1.5P-9.5VS5A

72×65×1

970

165

80

Single phase

1,173×418×855

92

72

1.5P-9.5V5A

Three phase

80

2.2

2.2P-9.5VS5A

72×65×2

730

265

90

Single phase

1,283×403×860

114

72

2.2P-9.5V5A

Three phase

97

3.7

3.7P-9.5V5A

L)90×85×1
H)50×85×1

1,000

440

125

Three phase

1,345×428×923

125

74

5.5

5.5P-9.5V5A

L)105×85×1
H)60×85×1

1,080

630

150

1,470×482×932

186

76

7.5

7.5P-9.5V5A

L)90×85×2
H)72×85×1

950

840

230

1,643×556×1,094

242

79

11

11P-9.5V5A

L)105×85×2
H)82×85×1

1,050

1,200

250

1,793×611×1,098

308

83





1. In an anechoic room, front 1.5m, at full load.

2. Use the compressor in an ambient temperature range of 0 to 40 °C.

3. This compressor series is not available for direct use of breathing air.



Lubricated BEBICON : Features

Point1. High Performance

  • Free air delivery increased through high efficiency.

In addition to a configurational change of the suction and discharge ports, the design of the valve has been modified from U to I shape so as to employ a flapper valve which minimizes leakage of compressed air. Provided for minimizing generation of heat during suction is a high-cooling head. All of these have further increased air delivery.

Point2. High Reliability

  • Temperature lowered with aluminum cylinder head and HITACHI's cooling fan.
  • High efficiency flapper valves employed for ling life of 10,000 hrs.

The main body has adopted a special light alloy having a long life. It is lighter and provides a higher efficiency than castings. In addition, temperature is kept low owing to use of the high-cooling head. In consequence, the lifetime of the air valve has been extended.

Point3. Compact and Light in Weight

  • Mounting area and weight reduced by aluminum cylinder head.

Each compressor has been designed so as to ensure a logical arrangement of the motor and control device, and to locate the gravity center as low as possible for the purpose of stabilization. Thus, installation is possible with minimal space. Both handling and transport have been made easier.

Point4. Easy to Maintain

  • Main spare parts designed the same as conventional type. Rings, connecting rod, and crank shaft (excluding high efficiency flapper valves)
  • Pressure gauge, pressure control devices and stop valves equipped in one manifold.

Point5. Approved Tank

  • Complies with ASME code section V||| division one. Certification of machinery department provided. (0.75 to 11kW)
